Okuma LB4000 II /1500 - Horizontal Lathes

Share Machine
Specifications Print Specs
Model: LB4000 II /1500
Year: 2013
Stock #: 13488-1 Sold
Highlights:

Okuma Space Turn LB4000EXII C-1500 CNC Lathe, OSP 300L, 15
Machine Specifications
# Axis
2
Control Type
OSP300L
Chuck Size
15"
Spindle Nose
A2-11
Swing
26.38"
Center Distance
59.84"
Bar Capacity
3.65"
X Axis Travel
11.81"
Z Axis Travel
62.60"
Max Cutting Diameter
18.9
X-Axis Rapid Traverse Rate
984
Z-Axis Rapid Traverse Rate
1,181
Spindle Speed (RPM)
3,000
Turret Capacity
12
Main Motor
40/50 Horsepower
Tailstock
yes
Weight
18,040 pounds

Equipped With:

IGF
Tool Holders
Touch Setter
Programmable Tailstock
Chip Conveyor

The Okuma LB4000 II /1500 is an exclusive part of our Horizontal Lathes inventory which we own and service. We're the international CNC specialists with the best guarantee in the industry.
