OKK HM600 - Horizontal Machining Centers

Share Machine
Specifications Print Specs
Model: HM600
Year: 2012
Stock #: 13568 Sold
Highlights:
Hydraulic Clamping
Tool Break Detection
High Pressure Coolant Through The Spindle
Spindle Chiller
Transformer
Chip Conveyor

OKK HM600 CNC Horizontal Machining Center
Machine Specifications
Pallet Indexing (B-Axis)
0.001°
X-Axis Travel
30.7"
Y-Axis Travel
29.5"
Z-Axis Travel
31.5"
Rapid Traverse Rate (X/Y/Z)
2,600 IPM
Spindle Taper
CAT 50
Spindle Speed
13,000
Spindle Motor (HP)
40 hp
Tool Changer Capacity
60
Coolant Through Spindle
yes
Machine Dimensions
168" x 120" x 123"
Machine Weight
31,500 pounds
CNC Control
yes
Control Type
Fanuc 310iS
# Axis
4
Pallet Length
24.8"
Pallet Width
24.8"
Pallet Load Capacity
1,540 pounds

Equipped With:

Hydraulic Clamping
Tool Break Detection
High Pressure Coolant Through The Spindle
Spindle Chiller
Transformer
Chip Conveyor

The OKK HM600 is an exclusive part of our Horizontal Machining Centers inventory which we own and service. We're the international CNC specialists with the best guarantee in the industry.
