Doosan 390L - Horizontal Lathes

Share Machine
Specifications Print Specs
Model: 390L
Year: 2001
Stock #: 13159 Sold
Highlights:
Fanuc 21T Control
12" Hydraulic 3 Jaw Chuck
Tailstock

2001 DOOSAN 390L - CNC Horizontal Lathe
Machine Specifications
CNC Control
yes
Control Type
Fanuc 21T
Chuck Size
12"
Swing
22.8"
Turning Diameter
15.35"
Center Distance
30"
Bar Capacity
3"
X Axis Travel
7.68"
Z Axis Travel
31"
Spindle Speed (RPM)
3,500
Main Motor
20 HP
Turret Capacity
12
Tailstock
yes
Y Axis
no
Weight
11,000 pounds
Live Tooling
no
Sub Spindle
no
# Axis
2

Equipped With:

- Fanuc 21T Control
- Chip Conveyor
- Coolant Tank
- 12" Hydraulic 3 Jaw Chuck
- Tailstock



Spindle Nose A2-8

The Doosan 390L is an exclusive part of our Horizontal Lathes inventory which we own and service. We're the international CNC specialists with the best guarantee in the industry.
